Defi DF10401 Link Meter Advance BF
||+50 ~ +150 (deg C)
Defi Link Meter Advance BF
Oil Temp Gauge
Defi-Link ADVANCE SYSTEM is the next generation system that adopted the interactive communication.
The Defi-Link ADVANCE system allows gauges and displays to be attached to the ADVANCE control unit with a single DAISY CHAIN wiring system.
Gauges, displays, and ADVANCE Control Unit are equipped with microcomputers. Distant gauges and displays can be operated at hand.
The system is also designed to allow all sensors to be attached to the ADVANCE control unit, so that gauges and displays can be mounted separately without the need for multiple tubing or wiring to each gauge.
The product of Defi-Link ADVANCE SYSTEM cannot be connected with the product of Defi-Link SYSTEM. It is not compatible with the product of Defi-Link SYSTEM.
- Interactive communication advanced system is implemented.
- Flat glass and precise graduation scale give more needle accuracy and high visibility.
- Gauges can be controlled from distance with the included switch unit.
- Opening and closing modes can be selected from 2 variations.
- The installation of additional gauges is easy. Just connect it with theother two gauges and attach the wire to Advance Control Unit.
- The illumination color can be chosen from white, amber red, and blue. (The illumination color cannot be changed.)
- The light-emitting gauge always provides clear visibility with high contrast.(The brightness is 200% compared to existing models.)
- The needle pointer driven by original stepping motor has a smooth instantaneous response to rapid acceleration of high performance vehicles.
- Brightness can be adjusted by selecting from five levels for daytime and nighttime separately.(nighttime dimming cancellation function is available.)
- The microcontroller calibrates up to 270 degree angle in 3027 4600 segments (0.088- 0.059), and provides accurate vehicle information.
- Self-diagnosis system turns the warning LED on to indicate any wire disconnection, short circuit and serial communication errors.
- Warning by buzzer sound when the warning LED is on (buzzer sound can be turned on / off).
- Peak value and warning value during driving are stored. Driving data can be stored and replayed up to 3 minutes.
- A mounting bracket, meter cup, regular position bezel are provided with this product.
- With both fuel pressure gauge and turbo installed, differential pressure can be monitored on the fuel pressure gauge screen.
