Specifications
|
Specifications |
|
|
Item Description |
HD/Race Sprung 6 Pad |
|
Product Weight (lbs.) |
11.7 |
|
Torque Capacity (ft/lbs.) |
330 |
|
Torque Capacity Over OE |
73% |
|
Disc Material |
Ceramic |
|
Clutch Disc Diameter (Inches) |
8.4 |
|
Clutch Disc Diameter (Millimeters) |
214 |
|
Input Shaft Diameter (inches) |
1.03125 |
|
Pressure Plate Type |
Heavy Duty |
|
Warranty |
12 Months (view details) |
Description
AR1-HDG6 kit features ACT's most popular Heavy Duty pressure plate. ACT Heavy Duty pressure plates use exclusive diaphragm design to increase clamp load, reduce deflection and maximize clutch life. All diaphragms endure a four-stage, heat-treating process for unparalleled performance. ACT pressure plates have precision cover stampings to provide rigidity and consistency. ACT's 6-pad, spring-centered race disc features a spring-center to properly damp torsional vibrations and resist failure under harsh conditions. ACT spring retainers utilize wraparound spring windows and thicker retainer stampings to provide spring support, reduce stress concentrations, and increase strength and reliability. With the 6-pad, spring-centered race disc, engagement is harsher, but shifting is faster. The 6-pad, spring-centered disc is recommended for larger clutch sizes to absorb more heat.
|
Description |
|
|
Feel |
Light to moderate pedal effort, aggressive engagement, OE to mild gear rattle |
|
Life |
Moderate friction life, extended by ACT's exclusive diaphragm design |
|
Quality |
Carefully engineered, precisely assembled, accurately balanced, uses select ceramic friction materials for high heat tolerance and maximum performance |
|
Recommended Use |
Recommended for high horsepower street or race use |
|
ACT Difference |
100% clamp load tested and dynamically computer balanced for smooth high RPM reliability |
Vehicle Fitment
Fitment Info
Application Engine
2002 Acura RSX Base 2.0 L4 GAS FI 1998cc
2002 Acura RSX Type-S 2.0 L4 GAS FI 1998cc
2002 Honda Civic Si 2.0 L4 GAS FI 1998cc
2002 Honda Civic SiR 2.0 L4 GAS FI 1998cc
2003 Acura RSX Base 2.0 L4 GAS FI 1998cc
2003 Acura RSX Type-S 2.0 L4 GAS FI 1998cc
2003 Honda Civic Si 2.0 L4 GAS FI 1998cc
2003 Honda Civic SiR 2.0 L4 GAS FI 1998cc
2004 Acura RSX Base 2.0 L4 GAS FI 1998cc
2004 Acura RSX Type-S 2.0 L4 GAS FI 1998cc
2004 Acura TSX Base 2.4 L4 GAS FI 2354cc
2004 Honda Civic Si 2.0 L4 GAS FI 1998cc
2004 Honda Civic SiR 2.0 L4 GAS FI 1998cc
2005 Acura RSX Base 2.0 L4 GAS FI 1998cc
2005 Acura RSX Type-S 2.0 L4 GAS FI 1998cc
2005 Acura TSX Base 2.4 L4 GAS FI 2354cc
2005 Honda Civic Si 2.0 L4 GAS FI 1998cc
2006 Acura RSX Base 2.0 L4 GAS FI 1998cc
2006 Acura RSX Type-S 2.0 L4 GAS FI 1998cc
2006 Acura TSX Base 2.4 L4 GAS FI 2354cc
2006 Honda Civic Si 2.0 L4 GAS FI 1998cc
2007 Acura TSX Base 2.4 L4 GAS FI 2354cc
2007 Honda Civic Si 2.0 L4 GAS FI 1998cc
2008 Acura TSX Base 2.4 L4 GAS FI 2354cc
2008 Honda Civic MUGEN Si 2.0 L4 GAS FI 1998cc
2008 Honda Civic Si 2.0 L4 GAS FI 1998cc
2009 Honda Civic Si 2.0 L4 GAS FI 1998cc
2010 Honda Civic Si 2.0 L4 GAS FI 1998cc
2011 Honda Civic Si 2.0 L4 GAS FI 1998cc
