Aeromotive Billet Hex Drive Fuel Pump P/N 11107

P/N 11107: Billet Drive Fuel Pump

Get the same unparalleled performance you get from our Billet Belt Drive Fuel Pump (P/N 11105), with the convenience of direct drive. The Hex Drive Fuel Pump can be mounted and driven directly from the back of a properly prepared external oil pump or driven directly by the cam through a timing cover adapter. Designed to solve fuel delivery problems in high horsepower, forced-induction EFI applications, as well as the now popular, carbureted applications on gas or methanol.

• Utilizes standard, 3/8′ hex drive shaft and adjustable, billet mounting
  collar with standard 3-bolt mounting pattern and hardware.
• Proven performance, powering some of the world’s fastest EFI vehicles.
• Carbureted, Naturally Aspirated Supports up to 3,900 HP gas, 2,700 E85, 1,350 HP methanol.
• Fuel Injected, Forced Induction Supports up to 3,000 HP on gas, 2,100 E85, 1,050 HP methanol.
• Compact size facilitates easy mounting.
• Billet aluminum CNC-machined body, not ‘cast’.
• ORB-10 inlet and outlet ports.
• For EFI applications use regulator P/N 13113.
• Carbureted gasoline applications require regulator P/N 13202 or P/N 13212.
• Alcohol applications require Double Adjustable Regulator P/N 13209 or 13214.Note: Electric Priming Kit available – P/N 17301 (see Accessories)

View Installation Instructions

Additional information

Mounting Configuration: External
