Brembo Prime UV Coated Rear Brake Rotor 300 x 12 mm - 08.D060.11

Rear Rotor | 300 x 12 mm | Audi | A4 | A5 Sportback

The Brembo Prime 08.D060.11 UV coated rear rotor is a practical factory-style replacement for worn brakes on your Audi. It is a good choice for routine brake service when you want to keep the original brake setup and get your vehicle back on the road with an OE-equivalent disc. The UV coating helps resist corrosion on the hub and outer edges, keeping the visible areas cleaner through everyday exposure to moisture and road grime. The 300 x 12 mm dimensions, 68 mm center bore and 36 mm overall height are important checks when matching the existing rear brakes. Requires the matching 300 x 12 mm solid rear brake package. Confirm the applicable factory PR brake code, including 1KI, 1KD or 1KE where specified.

Key Features & Specs:

• Brand/series: Brembo Prime; OE-equivalent replacement design
• Part number: 08.D060.11
• Axle position: Rear
• UV coating: helps resist corrosion on the rotor hub and outer edges
• Outside diameter: 300 mm
• Nominal thickness: 12 mm
• Minimum/discard thickness: 10 mm
• Overall height: 36 mm
• Center bore: 68 mm
• Hat inside diameter: 166 mm
• Hat outside diameter: 166.2 mm
• Offset: 28.9 mm
• Mounting bolt circle diameter: 112 mm
• Mounting hole diameter: 15.3 mm
• Rotor type: Solid
• Braking surface: Smooth
• Braking surface material: Gray Cast Iron
• Construction: Full cast
• Rotor mounting hole count: 5
• Fastening screws included: Yes
• ABS tone ring included: No
• Grade: Premium
• Rust-resistant coating: Yes
• Finish: Coated

Fitment:

• Requires the matching 300 x 12 mm solid rear brake package. Confirm the applicable factory PR brake code, including 1KI, 1KD or 1KE where specified.
• 2017–2020 Audi A4 — Premium, Premium Plus; L4 1,984 cc; 2017: 300X12Mm; 2018: Pr-1Ki
• 2018–2020 Audi A4 — Prestige; L4 1,984 cc; 2018: Pr-1Ki
• 2019 Audi A4 — Titanium; L4 1,984 cc
• 2021–2022 Audi A4 Quattro — Premium, Premium Plus, Prestige; L4 1,984 cc; 2021: 300X12Mm 5/112; 2022: 300X12Mm 5/112
• 2021–2022 Audi A5 Sportback — Premium, Premium Plus, Prestige; L4 1,984 cc; 2021: 300X12Mm 5/112; 2022: 300X12Mm 5/112

Match the part number, rotor dimensions and factory brake package before ordering. Replace brake rotors in axle pairs and follow the vehicle manufacturer’s installation and bedding instructions.
