Brembo Prime UV Coated Front Brake Rotor 355 x 32 mm - 09.D761.11

Front Rotor | 355 x 32 mm | Mercedes-Benz | G550

The Brembo Prime 09.D761.11 UV coated front rotor is a practical factory-style replacement for worn brakes on your Mercedes-Benz G550. It is a good choice for routine brake service when you want to keep the original brake setup and get your vehicle back on the road with an OE-equivalent disc. The UV coating helps resist corrosion on the hub and outer edges, keeping the visible areas cleaner through everyday exposure to moisture and road grime. Its high-carbon cast iron braking surface helps damp vibration for braking comfort. Pillar ventilation supports cooling and resistance to thermal cracking. The 355 x 32 mm dimensions, 85 mm center bore and 56.7 mm overall height are important checks when matching the existing front brakes. For the listed 355 x 32 mm front brake applications.

Key Features & Specs:

• Brand/series: Brembo Prime; OE-equivalent replacement design
• Part number: 09.D761.11
• Axle position: Front
• UV coating: helps resist corrosion on the rotor hub and outer edges
• High-carbon cast iron: supports vibration damping and braking comfort
• PVT pillar ventilation: promotes cooling and resistance to thermal cracking
• Outside diameter: 355 mm
• Nominal thickness: 32 mm
• Minimum/discard thickness: 29.4 mm
• Overall height: 56.7 mm
• Center bore: 85 mm
• Rotor type: Vented
• Braking surface: Smooth
• Braking surface material: High Carbon Cast Iron
• Construction: Full cast
• Rotor mounting hole count: 5
• Fastening screws included: Yes
• ABS tone ring included: No
• Grade: Premium
• Finish: Coated

Fitment:

• For the listed 355 x 32 mm front brake applications.
• 2019–2022 Mercedes-Benz G550 — Base

Match the part number, rotor dimensions and factory brake package before ordering. Replace brake rotors in axle pairs and follow the vehicle manufacturer’s installation and bedding instructions.
