Eagle SBC 350 Balanced Competition 4.030in Bore 3.750in Stroke Rotating Assembly - B12111030

Eagle SBC 350 Balanced Competition 4.030in Bore 3.750in Stroke Rotating Assembly - B12111030

Regular price $2,553.56 USD
Regular price Sale price $2,553.56 USD
Shipping calculated at checkout.
Eagle
Looking for the lowest price?

Give us a call to get the best prices and parts for your build. Or, just call us with a cool racing story...either way we're here.

EAGB12111030
Looking for the lowest price?

Give us a call to get the best prices and parts for your build. Or, just call us with a cool racing story...either way we're here.

B12111030
Looking for the lowest price?

Give us a call to get the best prices and parts for your build. Or, just call us with a cool racing story...either way we're here.

Ships from the MFG
Rotating Assemblies
Giving your small-block Chevy 350 a fresh start? This Eagle Competition rotating assembly uses Mahle flat-top pistons with a 4.030 in bore and 3.750 in stroke. The 6.000 in rods...
Read more
Found a better price elsewhere?
secure-payments
View full details

Giving your small-block Chevy 350 a fresh start? This Eagle Competition rotating assembly uses Mahle flat-top pistons with a 4.030 in bore and 3.750 in stroke. The 6.000 in rods and -5 cc piston crown volume are dimensions to match to your block and cylinder heads.

Specifications

Brand Eagle
Manufacturer Part Number B12111030
Product Type Rotating assembly
Quantity 1 assembly
Engine / Application SBC 350
Assembly Balanced Yes
Balance Configuration Internal
Connecting Rod Bolt Diameter 7/16 in
Connecting Rod Bolt Material ARP8740
Connecting Rod Design H-beam
Connecting Rod Length 6.000 in
Connecting Rod Material Forged 4340 Steel
Crankshaft Center Counterweights No
Crankshaft Flange Bolt Holes 6
Crankshaft Main Journal Diameter 2.449 in
Crankshaft Material Forged 4340 Steel
Crankshaft Reluctor No
Crankshaft Rod Journal Diameter 2.100 in
Crankshaft Stroke 3.750 in
Cylinder Bore Diameter 4.030 in
Damper Included No
Flexplate / Flywheel Included No
Main Bearing Type Hardened, narrowed or chamfered
Main Bearings Included Yes
Oil Rail Support Included No
Piston Brand Mahle
Piston Crown Volume -5 cc
Piston Face Type Flat top
Piston Material Forged 4032 Aluminum
Piston Pin Diameter 0.927 in
Piston Pin Type Full Floating
Piston Ring Gap File-fit
Piston Ring Thickness 1.0 mm / 1.0 mm / 2.0 mm
Rod Bearing Type Hardened, narrowed or chamfered
Rod Bearings Included Yes
Second Piston Ring Type Reverse Twist Iron
Thrust Washer Included No
Top Piston Ring Type Barrel Faced Plasma-Moly
Assembly Type Balanced Competition Assembly
Piston Type Flat Top Forged 4032
Product Line Competition

Notes

Damper and flexplate / flywheel are not included.
