Planning the next step for your small-block Chevy? This Eagle H-beam rod is made from forged 4340 steel and uses 3/8 in ARP2000 bolts. The 6.200 in center-to-center length and 0.927 in piston-pin diameter identify the dimensions to match to your crankshaft and pistons. Sold individually for a replacement or custom combination.
| Brand | Eagle |
|---|---|
| Manufacturer Part Number | CRS6200BLW-1 |
| Product Type | Connecting rod |
| Engine / Application | SBC |
| Quantity | 1 rod |
| Material | Forged 4340 steel |
| Center-to-Center Length | 6.200 in |
| Rod Bolts | 3/8 in ARP2000 |
| Housing Bore | 2.225 in |
| Piston Pin Diameter | 0.927 in |
| Rod Journal Diameter | 2.100 in |
| Big End Width | 0.940 in |
| Bushed for Full-Floating Piston Pins | Yes |
| Pin End Width | 1.060 in |
| Connecting Rod Length | 6.200 in |
| Connecting Rod Design | H-beam |
| Weight Configuration | Lightweight |
| Rod Design | H-beam |
