Eagle Extreme Duty H-Beam Connecting Rod Dodge Neon 2.0L - CRS5472NXD-1

Eagle Extreme Duty H-Beam Connecting Rod Dodge Neon 2.0L - CRS5472NXD-1

Regular price $219.68 USD
Regular price Sale price $219.68 USD
Shipping calculated at checkout.
Eagle
Looking for the lowest price?

Give us a call to get the best prices and parts for your build. Or, just call us with a cool racing story...either way we're here.

EAGCRS5472NXD-1
Looking for the lowest price?

Give us a call to get the best prices and parts for your build. Or, just call us with a cool racing story...either way we're here.

CRS5472NXD-1
Looking for the lowest price?

Give us a call to get the best prices and parts for your build. Or, just call us with a cool racing story...either way we're here.

Ships from the MFG
Connecting Rods - Single
Have a Dodge Neon 2.0L combination in mind? This Eagle Extreme Duty H-beam rod is made from forged 4340 steel and uses 3/8 in ARP Custom Age 625+ bolts. The...
Read more
Found a better price elsewhere?
secure-payments
View full details

Have a Dodge Neon 2.0L combination in mind? This Eagle Extreme Duty H-beam rod is made from forged 4340 steel and uses 3/8 in ARP Custom Age 625+ bolts. The 5.472 in center-to-center length and 21 mm piston-pin diameter identify the dimensions to match to your crankshaft and pistons. Sold individually for a replacement or custom combination.

Specifications

Brand Eagle
Manufacturer Part Number CRS5472NXD-1
Product Type Connecting rod
Engine / Application Dodge Neon 2.0L
Quantity 1 rod
Material Forged 4340 steel
Center-to-Center Length 5.472 in
Rod Bolts 3/8 in ARP Custom Age 625+
Piston Pin Diameter 21 mm
Housing Bore 2.008 in
Rod Journal Diameter 1.890 in
Big End Width 1.032 in
Bushed for Full-Floating Piston Pins Yes
Pin End Width 1.030 in
Rod Design H-beam
