Putting a Honda H23/F22 build together? This Eagle Extreme Duty H-beam rod is made from forged 4340 steel and uses 3/8 in ARP Custom Age 625+ bolts. The 5.571 in center-to-center length and 0.866 in piston-pin diameter identify the dimensions to match to your crankshaft and pistons. Sold individually for a replacement or custom combination.
| Brand | Eagle |
|---|---|
| Manufacturer Part Number | CRS5571HXD-1 |
| Product Type | Connecting rod |
| Engine / Application | Honda H23/F22 |
| Quantity | 1 rod |
| Rod Bolts | 3/8 in ARP Custom Age 625+ |
| Housing Bore | 2.008 in |
| Material | Forged 4340 Steel |
| Piston Pin Diameter | 0.866 in |
| Rod Journal Diameter | 1.889 in |
| Pin End Width | 0.940 in |
| Big End Width | 0.940 in |
| Bushed for Full-Floating Piston Pins | Yes |
| Center-to-Center Length | 5.571 in |
| Rod Design | H-beam |
