Giving your VW/Audi VR6 a fresh start? This Eagle H-beam rod is made from forged 4340 steel and uses 5/16 in ARP2000 bolts. The 6.457 in (164 mm) center-to-center length and 20 mm piston-pin diameter identify the dimensions to match to your crankshaft and pistons. Sold individually for a replacement or custom combination.
| Brand | Eagle |
|---|---|
| Manufacturer Part Number | CRS6457V13D-1 |
| Product Type | Connecting rod |
| Engine / Application | VW/Audi VR6 |
| Quantity | 1 rod |
| Material | Forged 4340 steel |
| Center-to-Center Length | 6.457 in (164 mm) |
| Rod Bolts | 5/16 in ARP2000 |
| Piston Pin Diameter | 20 mm |
| Typical Rod Weight | 555 g |
| Housing Bore | 2.237 in |
| Rod Journal Diameter | 2.125 in |
| Big End Width | 0.784 in |
| Bushed for Full-Floating Piston Pins | Yes |
| Pin End Width | 0.784 in |
| Rod Design | H-beam |
