EZ LYNK Auto Agent 3 Heavy-Duty 9-Pin Cable - 100EE00C17

The EZ LYNK Auto Agent 3 Heavy-Duty 9-Pin Cable, part number 100EE00C17, connects Auto Agent 3 hardware to compatible medium- and heavy-duty vehicle diagnostic systems using a 9-pin round connector. It supports SAE J1939 high- and low-speed communication and is compatible with supported EZ LYNK ELD applications.

Key Features & Specs:

• Part Number: 100EE00C17
• UPC: 857218007075
• Series: Auto Agent 3
• Auto Agent Compatibility: Auto Agent 3 only
• Connector: 9-pin weatherproof round / Deutsch-style connector
• Protocol: SAE J1939
• Baud Support: High-speed and low-speed variants
• Cable Length: 20 in
• Color: Black / green connector identification
• ELD Compatibility: Compatible with supported EZ LYNK ELD applications
• Package Weight: 0.74 lb
• Package Dimensions: 5.38 x 3.25 x 2.63 in
• Quantity: Each

Fitment:

• Compatible medium- and heavy-duty vehicles using the supported 9-pin SAE J1939 diagnostic connection

What's Included:

• Auto Agent 3 heavy-duty 9-pin diagnostic cable
