DESCRIPTION
2014-18 CHEVY SILVERADO 1500 | GMC SIERRA 1500 2WD/4WD
Fabtech’s 4″ Basic systems utilize their proven heavy duty construction and design features found in their 6″ systems but with less lift for use with 33″ tall tires. These 4″ systems feature high arched lower control arm crossmembers constructed of 1/4″ thick steel for maximum strength. The Fabtech ductile iron steering knuckles retain the stock track width keeping tires under the fender for a clean appearance. Rear lift is accomplished with a block and u-bolt configuration.
The Basic System includes front coilover spacers that utilize the factory Coilover shocks and rear Performance shocks.
FEATURES
- Heavy Duty 1/4″ Thick, High Arched Crossmember
- Front Differential Skid Plate
- Ductile Iron Steering Knuckles
- Rear Block & U-bolt Kit
PART NUMBERS
QTY | PART # | DESCRIPTION |
---|---|---|
1 | FTS21226 | COMPONENT BOX 1 |
1 | FTS21229 | COMPONENT BOX 2 |
1 | FTS21227 | FRONT COIL SPACERS |
2 | FTS7333 | REAR PERFORMANCE SHOCKS |
ADDITIONAL INFORMATION
MAKE
CHEVY, GMC
MODEL
C1500, K1500
DRIVE
2WD, 4WD
YEAR
2014, 2015, 2016, 2017, 2018
SYSTEMS
BASIC
LIFT
4"
TIRES & WHEELS
- Tire Size – 33/12.50R17 Wheel Size – 17×8 w/ 4 1/2in BS w/minor trimming
- Tire Size – 275/65R18 Wheel Size – 18×8 w/ 4 1/2in BS w/minor trimming
- Tire Size – 295/55R20 Wheel Size – 20×9 w/ 5in BS w/minor trimming
INCLUDED SHOCKS
PERFORMANCE TWIN TUBE SHOCK
Fabtech Performance Shocks have been designed to work in conjunction with each of our suspension systems, resulting in superior ride control. Features include high velocity 9-stage valving for excellent dampening capabilities and a closed cell insert to reduce shock fade at high speeds.
- Twin Tube Hydraulic Construction
- 9/16″ Hardened Chrome Piston Rod
- 1 3/8″ OD Piston
- Closed Cell Foam insert
- High Flow 9 Stage Valving
