DESCRIPTION
2015-20 FORD F150 4WD
Fabtech’s 4” F150 system utilizes their proven heavy duty construction and design features found in their 6” systems but with less lift and at a much lower price. This 4” System allows use of 33” tall tires and features high arched lower control arm crossmembers constructed of 1/4 “ thick steel for maximum strength. The Fabtech ductile iron steering knuckles retain the stock track width keeping tires under the fender for a clean appearance. Rear lift is accomplished with a block and u-bolt configuration.
The Basic System includes heavy duty front Coilover shocks for increased dampening capacity while retaining the factory coil springs and Fabtech’s Performance rear shocks.
The 4” System allows use of 33” tires and is ESC (Electronic Stability Control) and Traction Control compliant.
FEATURES
- Heavy Duty 1/4" Thick, High Arched Crossmember
- Ductile Iron Steering Knuckles
- Front Coilover Spacers
- Rear Block & U-bolt Kit
PART NUMBERS
OTY | PART # | DESCRIPTION |
---|---|---|
1 | FTS22176 | COMPONENT BOX 1 |
1 | FTS22177 | COMPONENT BOX 2 |
2 | FTS7266 | REAR PERFORMANCE SHOCKS |
ADDITIONAL INFORMATION
YEAR
2015, 2016, 2017, 2018, 2019, 2020
MAKE
FORD
MODEL
F150
DRIVE
4WD
LIFT
4"
TIRES & WHEELS
- Tire Size – 33/12.50R18 Wheel Size – 18×9 w/ 5in BS w/minor trimming
- Tire Size – 295/70R18 Wheel Size – 18×9 w/ 5in BS w/minor trimming
- Tire Size – 33/12.50R20 Wheel Size – 20×9 w/ 5in BS w/minor trimming
- Tire Size – 295/60R20 Wheel Size – 20×9 w/ 5in BS w/minor trimming
INCLUDED SHOCKS
PERFORMANCE TWIN TUBE SHOCK
Fabtech Performance Shocks have been designed to work in conjunction with each of our suspension systems, resulting in superior ride control. Features include high velocity 9-stage valving for excellent dampening capabilities and a closed cell insert to reduce shock fade at high speeds.
- Twin Tube Hydraulic Construction
- 9/16″ Hardened Chrome Piston Rod
- 1 3/8″ OD Piston
- Closed Cell Foam insert
- High Flow 9 Stage Valving
