Fabtech 15-20 Ford F150 4WD 4″ BASIC SYSTEM W/REAR STEALTH SHOCKS – K2193M

Fabtech’s 4” F150 system utilizes their proven heavy duty construction and design features found in their 6” systems but with less lift and at a much lower price. This 4” System allows use of 33” tall tires and features high arched lower control arm crossmembers constructed of 1/4 “ thick steel for maximum strength. The Fabtech ductile iron steering knuckles retain the stock track width keeping tires under the fender for a clean appearance. Rear lift is accomplished with a block and u-bolt configuration.

The Basic System includes heavy duty front Coilover shocks for increased dampening capacity while retaining the factory coil springs and Fabtech’s Stealth rear shocks.

The 4” System allows use of 33” tires and is ESC (Electronic Stability Control) and Traction Control compliant.

FEATURES

• Heavy Duty 1/4″ Thick, High Arched Crossmember
• Ductile Iron Steering Knuckles
• Front Coilover Spacers
• Rear Block & U-bolt Kit

PART NUMBERS

ADDITIONAL INFORMATION
YEAR
2015, 2016, 2017, 2018, 2019, 2020

MAKE
FORD

MODEL
F150

DRIVE
4WD

LIFT
4"

TIRES & WHEELS

• Tire Size – 33/12.50R18 Wheel Size – 18×9 w/ 5in BS w/minor trimming
• Tire Size – 295/70R18 Wheel Size – 18×9 w/ 5in BS w/minor trimming
• Tire Size – 33/12.50R20 Wheel Size – 20×9 w/ 5in BS w/minor trimming
• Tire Size – 295/60R20 Wheel Size – 20×9 w/ 5in BS w/minor trimming

INCLUDED SHOCKS

STEALTH MONOTUBE SHOCK

Stealth is the first all black monotube shock absorber, with an identifiable raised metal nameplate, that represents the signature of quality you can rely on for a superior ride at an affordable price.

Stealth monotube shocks are built with a 46mm diameter high flow piston and vehicle specific valving, for a great ride with oversized tires.

All Stealth shock absorbers feature Nitrocarburized piston rods that are superior to chromed rods in durability and corrosion resistance. These Nitrocarb piston rods are finished in matte black for a complete black out shock package.

• 50mm OD Seamless Steel Body
• 46mm High Flow Piston for best ride
• Vehicle specific valving designed for oversized tires
• Full floating piston separates gas from oil for a consistent ride
• 14mm Nitrocarb piston rod resists rock chips and rusting
• All black finish with raised nameplate as a signature of quality
