Fleece Camshaft Sensor Pigtail for 2003-2010 Ford F-250/F-550 Super Duty - FPE-HAR-FMC-CAM-0310

Key Features & Specs:

• Brand: Fleece Performance
• Part Number: FPE-HAR-FMC-CAM-0310
• Application: Camshaft position sensor connector pigtail
• Engine Compatibility: 6.0L and 6.4L Powerstroke
• Connector Style: Pigtail connector
• Connector Family: SSC Series
• Connector Type: Female
• Pins Per Connector: 2
• Wire Length: 48-inch pigtail
• Connector Color: Black
• Weather-Resistant: Yes
• Included: Heat-sealable butt-splice connectors
• Quantity: Sold individually
• Installation Benefit: Extended lead supports routing the repair connection to an accessible location at the top of the engine
• 6.0L Wire Colors: Red and orange to match the OE harness
• 6.4L Wire Colors: Yellow/violet or green/brown OE harness configurations
• Warranty: 6-month limited parts warranty

Fitment:

• 2003-2007 Ford F-250 Super Duty 6.0L Powerstroke
• 2003-2007 Ford F-350 Super Duty 6.0L Powerstroke
• 2003-2007 Ford F-450 Super Duty 6.0L Powerstroke
• 2003-2007 Ford F-550 Super Duty 6.0L Powerstroke
• 2008-2010 Ford F-250 Super Duty 6.4L Powerstroke
• 2008-2010 Ford F-350 Super Duty 6.4L Powerstroke
• 2008-2010 Ford F-450 Super Duty 6.4L Powerstroke
• 2008-2010 Ford F-550 Super Duty 6.4L Powerstroke

Repair a damaged camshaft position sensor connection with the Fleece Performance Camshaft Position Sensor Pigtail for 2003-2010 Ford Powerstroke trucks. This weather-resistant black 2-pin female connector features an extended 48-inch pigtail, allowing the harness to be routed from the sensor to a more accessible location on top of the engine. Built in-house with automated wire cutting and terminal crimping, it includes heat-sealable butt-splice connectors for a reliable, service-ready repair.
