FOX 2.5 x 3.8in Factory Race Hydraulic Bump Stop Emulsion - 981-25-041

2.5in body | 3.75in travel | 2.5 x 3.8in nominal size | Sold as Each

FOX 981-25-041 2.5 Factory Race Hydraulic Bump Stop is configured for a custom motorsports suspension build. A hydraulic bump stop adds controlled damping near the end of suspension compression. Match its mounting configuration and travel to the suspension setup; bump-stop travel is separate from vehicle lift. Key dimensions are body diameter: 2.5in; extended length: 14.9in; compressed length: 11.15in; travel: 3.75in. Check the full mounting requirements before selecting parts for the chassis.

Key Features & Specs:

• Brand: FOX
• Part number: 981-25-041
• Series: 2.5 Factory Race Bump Stop
• Type: Bump Stop
• Body diameter: 2.5in
• Extended length: 14.9in
• Compressed length: 11.15in
• Travel: 3.75in
• Top mount: Stem
• Bottom mount: None
• Reservoir / oil separation: Emulsion
• Material: Steel
• Sold as: Each
• Country of origin: Proudly made in the USA
• Nominal size designation: 2.5 x 3.8in
• Cerakote® protective ceramic coating over a zinc-plated base coat
• hard chrome plated 4130 chromoly steel shaft
• Owner-serviceable and rebuildable construction
• JM92 MIL-SPEC oil developed for off-road racing
• Black-anodized, CNC-machined aluminum components

Fitment:

• No vehicle-specific application is provided in the FOX fit guide. Select using the supplied dimensions, mounting configuration, and custom-build requirements.
