FOX 2.5 Performance HTO Front Smooth Body Shock IFP for Ford F-250/F-350 Super Duty - 987-24-020

Front | 2.5in body | 9.29in travel | Ford F-250/F-350 Super Duty | HTO | Sold as Each

FOX 987-24-020 2.5 Performance HTO Front Smooth Body Shock is configured for Ford F-250/F-350 Super Duty. The supplied Hydraulic Top Out feature adds control near full suspension extension. Choose the listed dimensions and mounting configuration for the specified application. Key dimensions are body diameter: 2.5in; travel: 9.29in. Keep the full vehicle, lift, drivetrain and installation notes below with this part when checking compatibility.

Key Features & Specs:

• Brand: FOX
• Part number: 987-24-020
• Series: 2.5 Performance Shock
• Type: Smooth Body
• Body diameter: 2.5in
• Extended length: 26.29in
• Compressed length: 17in
• Travel: 9.29in
• Top mount: Stem
• Bottom mount: Eyelet
• Reservoir / oil separation: Internal floating piston (IFP)
• Material: Aluminum
• Sold as: Each
• Country of origin: Proudly made in the USA
• Position: Front
• Technology / variant: Hydraulic Top Out (HTO); Internal floating piston (IFP)
• 2.5” Impact extruded 6061-T6 aluminum shock body
• Type II clear-anodized body plating
• High-flow velocity-sensitive damping
• 5/8” hard chrome shaft
• Internal floating piston (IFP)

Fitment:

• 2017-2019 Ford F-250 Super Duty | Front | 4WD drivetrain | Front lift: 6in
• 2020-2026 Ford F-250 Super Duty | Front | 4WD drivetrain | Front lift: 7in | 5" lift on Tremor
• 2017-2019 Ford F-350 Super Duty Crew Cab Pickup | Front | 4WD drivetrain | Front lift: 6in
• 2020-2026 Ford F-350 Super Duty Crew Cab Pickup | Front | 4WD drivetrain | Front lift: 7in | 5" lift on Tremor
• 2017-2019 Ford F-350 Super Duty Extended Cab Pickup | Front | 4WD drivetrain | Front lift: 6in
• 2020-2026 Ford F-350 Super Duty Extended Cab Pickup | Front | 4WD drivetrain | Front lift: 7in | 5" lift on Tremor
• 2017-2019 Ford F-350 Super Duty Standard Cab Pickup | Front | 4WD drivetrain | Front lift: 6in
• 2020-2026 Ford F-350 Super Duty Standard Cab Pickup | Front | 4WD drivetrain | Front lift: 7in | 5" lift on Tremor
