FOX 2.0 Performance Rear Smooth Body Shock IFP for Ford F-450/F-550 Super Duty - 980-24-656

Rear | 2.0in body | 9.11in travel | Ford F-450/F-550 Super Duty | Sold as Each

FOX 980-24-656 2.0 Performance Rear Smooth Body Shock is configured for Ford F-450/F-550 Super Duty. The internal floating piston separates damping oil from pressurized nitrogen, helping maintain controlled damping as the suspension works. Choose the listed axle and lift configuration to match this FOX version to your vehicle. Key dimensions are body diameter: 2.0in; travel: 9.11in. Keep the full vehicle, lift, drivetrain and installation notes below with this part when checking compatibility.

Key Features & Specs:

• Brand: FOX
• Part number: 980-24-656
• Series: 2.0 Performance Shock
• Type: Smooth Body
• Body diameter: 2.0in
• Extended length: 24.81in
• Compressed length: 15.7in
• Travel: 9.11in
• Top mount: EB2
• Bottom mount: ES1
• Reservoir / oil separation: Internal floating piston (IFP)
• Material: Aluminum
• Sold as: Each
• Top mount reference: 014-11-003-A
• Bottom mount reference: 213-27-000-B
• Country of origin: Proudly made in the USA
• Position: Rear
• Technology / variant: Internal floating piston (IFP)
• FOX tuning developed for the specific vehicle application
• Aluminum body helps dissipate heat faster than steel
• Internal floating piston (IFP) separates the oil from high-pressure nitrogen gas
• Black-anodized, CNC-machined aluminum components

Fitment:

• 1999-2004 Ford F-450 Super Duty Cab & Chassis - Conventional | Rear | All drivetrains | Rear lift: 0-1in
• 2005-2016 Ford F-450 Super Duty Cab & Chassis - Conventional | Rear | All drivetrains | Rear lift: 0-1.5in
• 1999-2004 Ford F-450 Super Duty Cab & Chassis - Crew Cab | Rear | All drivetrains | Rear lift: 0-1in
• 2005-2016 Ford F-450 Super Duty Cab & Chassis - Crew Cab | Rear | All drivetrains | Rear lift: 0-1.5in
• 2002-2004 Ford F-450 Super Duty Cab & Chassis - Extended Cab | Rear | All drivetrains | Rear lift: 0-1in
• 2005-2016 Ford F-450 Super Duty Cab & Chassis - Extended Cab | Rear | All drivetrains | Rear lift: 0-1.5in
• 1999-2004 Ford F-550 Super Duty | Rear | All drivetrains | Rear lift: 0-1in
• 2005-2016 Ford F-550 Super Duty | Rear | All drivetrains | Rear lift: 0-1.5in
