FOX 3.0 Factory Race QAB Rear External Bypass Shock Piggyback Reservoir for 2017-18 Ford F-150 Raptor - 883-09-141

Rear | 2.5in body | 0-1in lift | Ford F-150 Raptor | QAB | Sold as Pair

FOX 883-09-141 3.0 Factory Race QAB Rear External Bypass Shock Kit is configured for 2017-2018 Ford F-150 Raptor. External bypass damping provides another way to shape shock response through the suspension’s travel. Match this version to the listed vehicle, axle and lift range when planning the suspension upgrade. Key dimensions are body diameter: 2.5in; travel: 12.27in; listed lift: 0-1in. Keep the full vehicle, lift, drivetrain and installation notes below with this part when checking compatibility.

Key Features & Specs:

• Brand: FOX
• Part number: 883-09-141
• Series: 3.0 Factory Race Bypass Shocks
• Type: External Bypass
• Body diameter: 2.5in
• Extended length: 31.15in
• Compressed length: 18.88in
• Travel: 12.27in
• Top mount: Eyelet
• Bottom mount: Eyelet
• Reservoir / oil separation: Piggyback
• Material: Steel
• Sold as: Pair
• Country of origin: Proudly made in the USA
• Position: Rear
• Technology / variant: Quick Adjust Bypass (QAB)
• FOX tuning developed for the specific vehicle application
• Seamless alloy body with a durable zinc-plated finish
• Quick Adjust Bypass knobs simplify damping adjustments
• External reservoir helps dissipate heat during operation

Fitment:

• 2017-2018 Ford F-150 Raptor | Rear | All drivetrains | Rear lift: 0-1in
