ICON Rear 3.0 Zeta Piggyback Shock Pair for 2010-2014 Raptor - 95200

ICON's Rear Zeta Ford SVT Raptor Shocks are a true 3.0” (inside and out), three tube External Bypass shock. These are far from the norm when compared to a traditional bypass shock you see on Trophy Trucks and other off-road race vehicles. Each bypass valve has a specific port design and individually equipped with a different spring rate to ensure proper performance at each zone of shock travel. These same bypass valves feature dampened valve stops for quiet and precise operation. That means no clicking noises as you hit bumps or road chatter driving down the road. The biggest difference in these shocks versus an industry standard bypass shock, are the “Easy-to-Adjust” knobs and the replaceable bypass tubes. The “Easy to Adjust” Hi Resolution Clicker Knobs do not require any tools for adjustment, and can be adjusted in seconds from plush off-road performance to firm on road manners for extra control while driving the mountains or towing a trailer. Another unique feature of this shock is the replaceable bypass tubes that can be swapped out during a standard rebuild if any damage were to occur, where a normal bypass shock body would need to be completely replaced, saving you hundreds of dollars.

This Part Fits:

Features

• Large 3.0-inch shock platform for demanding applications
• Fully rebuildable and re-tunable design
• Increased piston area and oil volume for control and heat management
• Piggyback reservoir adds oil/gas volume in a compact package

Specifications

• Brand: ICON Vehicle Dynamics
• Product Type: Shocks and Struts
• Manufacturer Part Number: 95200
• Variant SKU: ICO95200
• Series / Product Family: VEHICLE SPECIFIC (V.S) 3.0 SERIES | OPTIONS: C = CDC VALVE SHOCK IR: INTERNAL RESERVOIR PB: PIGGYBACK RR: REMOTE RESERVOIR
• GTIN: 00840103407180
• Weight: 47 lb
• Application: 2010-2014 Raptor

Product Family

ICON V.S. 3.0 Series shocks use increased piston area and oil volume to improve control and heat management under severe use. They are fully rebuildable and re-tunable, making them a serious upgrade for heavier or aggressively driven off-road vehicles.

Fitment

Year	Make	Model	Submodel
2010-2014	Ford	F-150	SVT Raptor
