ICON 0-3in Stage 5 Billet UCA Suspension System for 1996-2002 4Runner - K53135B

Upgrade the suspension on your 1996-2002 4Runner with the ICON Vehicle Dynamics 0-3in Stage 5 Billet UCA Suspension System, part number K53135B. This complete kit brings the specified ICON suspension components together in one package, giving you an easier way to buy the full system without tracking down each part individually.

With the ICON Stage 5 suspension system on and off-road performance is significantly improved with 2.5 Series Extended Travel Remote Reservoir Coilovers and 2.5 Aluminum Series Remote Reservoir Rear Shocks that feature ICON engineered coil springs, vehicle-specific shock valving, FK Rod End bearings, and high-quality CNC-machined components for superior damping and control. ICON’s CDC (Compression Damping Control) Valve option adds to the adjustability of these shocks, allowing the end-user to adjust the ride characteristics of the vehicle with the turn of a knob. The 2.5 Aluminum Series coilovers are height adjustable from 0-3” of lift over stock, allowing the use of larger, more aggressive wheel and tire combinations.

For buyers who want the complete 0-3in Stage 5 Billet UCA Suspension System instead of piecing a suspension together one part number at a time, the K53135B kit keeps the listed ICON components together as one package. You can see exactly what is included below, along with the application and wheel/tire notes needed to confirm the setup for your vehicle.

• Brand: ICON Vehicle Dynamics
• Part Number: K53135B
• System: 0-3in Stage 5 Billet UCA Suspension System
• Fitment: 1996-2002 4Runner
• Configuration: Billet upper control arm configuration
• Total Kit Weight: 117 lb

• Qty 1 – 58716C: 96-02 4Runner Ext Travel 2.5 VS RR CDCV Coilover Kit
• Qty 1 – 58500DJ: 96-04 Tacoma/96-02 4Rnr Billet UCA Dj Kit
• Qty 1 – 53015: 96-02 4Runner 1" Rear Coil Spring Kit
• Qty 1 – 57800CP: 96-02 4Runner Rear 2.5 VS CDCV RR Pair

• Application Notes: 18, 35, 47, 55, 111
• Tire & Wheel: 33X11.25 On 8.5" Wide Wheel W/ 4.75" Backspace

• 1996-2002 4Runner
