• MANLEY 606010C-4 Platinum Series Lightweight Pistons Set of 4 Includes Ringset Part # 46860-4 - eliteracefab.com
  • MANLEY 606010C-4 Platinum Series Lightweight Pistons Set of 4 Includes Ringset Part # 46860-4 - eliteracefab.com
1 2

MANLEY 606010C-4 Platinum Series Lightweight Pistons Set of 4 Includes Ringset Part # 46860-4

MANLEY 606010C-4 Platinum Series Lightweight Pistons Set of 4 Includes Ringset Part # 46860-4

$635.38 USD
$760.03 USD $635.38 USD
-16%
Shipping calculated at checkout.
Manley Performance
Looking for the lowest price?

Give us a call to get the best prices and parts for your build. Or, just call us with a cool racing story...either way we're here.

Phone Call or Text 336-900-7223

Email - support@eliteracefab.com

MAN606010C-4
Looking for the lowest price?

Give us a call to get the best prices and parts for your build. Or, just call us with a cool racing story...either way we're here.

Phone Call or Text 336-900-7223

Email - support@eliteracefab.com

606010C-4
Looking for the lowest price?

Give us a call to get the best prices and parts for your build. Or, just call us with a cool racing story...either way we're here.

Phone Call or Text 336-900-7223

Email - support@eliteracefab.com

In stock
Piston Sets - Forged - 4cyl
Product Note: Platinum Series Lightweight Pistons Set of 4 Includes Ringset Part # 46860-4 Specs: Bore: 86mm (+1.0mm) Comp Distance: 1.375" Comp Ratio: 8.5 / 9.0:1 Cylinder Head: 47 /...
Read more
Same Day Shipping Icon | Elite Race Fab

Free* Shipping on Orders Over $159

 Free Shipping | Elite Race Fab

Easy 30 Days- No Hassle Returns

 5 Star Reviews | Elite Race Fab

37,000+ 5 Star Reviews

 MFG Fitment Guarantee | Elite Race Fab

MFG Fitment Guarantee
Found a better price elsewhere?
secure-payments
View full details

Description

Product Note:

Platinum Series Lightweight Pistons Set of 4 Includes Ringset Part # 46860-4

Specs:

Bore: 86mm (+1.0mm)
Comp Distance: 1.375"
Comp Ratio: 8.5 / 9.0:1
Cylinder Head: 47 / 43cc
Dome Volume: -12cc
Piston Type: Dish
Rod Length: 150mm
Stroke: 88mm
Weight: 345g

Manley pistons are machined of high strength 2618 material. Each design is lightweight yet robust enough to deliver long service life. Perfect ring groove to skirt squareness is achieved through our unique “one fixturing” manufacturing method that assures maximum horsepower. Round wire locks, tool steel wrist pins, and rings are included with every set at no additional charge.

Forging

  • 2618 alloy for maximum high temperature strength and fatigue resistance.

Attributes

  • “Contour forgings” provide the optimum balance between strength and weight with no grain-interrupting internal milling.
  • Proprietary multi-step top ring groove machining process assures optimum control of the groove’s size, geometry, flatness, and finish.
  • All final turning is performed in one fixturing resulting in complete squareness of rings to the cylinder wall.
  • Federal Form-Scan gauging validates ideal skirt indexing to pinhole and skirt-to-skirt polarity.
  • Value – added features such as a pressure balance groove included in all series.
  • Precise pinhole machining results in an exact compression distance as well as precise lock ring groove spacing, size, and concentricity.

Manley Sport Compact Platinum series pistons come complete with pistons, rings, pins, and locks
