PLM Vertical Flow Intercooler XL – K-Series Same Side Inlet/Outlet

Part Number: PLM-IC-VF-XL

Product Name or Type: Vertical Flow Intercooler XL – Same Side Inlet/Outlet

Vehicle Fitment:

• Honda / Acura K-Series K20, K24 Turbo Engines
• Acura RSX DC5 with K-Series Turbo
• Honda Civic with K-Series Turbo
• Acura Integra with K-Series Turbo
• Turbo setups requiring same-side inlet/outlet configuration

Description:

The PLM Vertical Flow Intercooler XL is engineered for K-Series turbo applications demanding high flow and efficient cooling. Featuring same-side 3.0" inlet and outlet ports, this XL version delivers maximum cooling capacity in a compact footprint. Its bar-and-plate core design ensures optimal heat dissipation, while the thick 4.5" core supports up to 1000HP. Built for performance and durability under high boost conditions.

Key Features and Benefits:

• Extra-large core size: 27" x 6" x 4.5"
• High-density air-to-air intercooler core
• Bar and plate construction for durability and efficiency
• 3.0" inlet and outlet (same side)
• Fully TIG welded for strength
• Rated for up to 1000 horsepower

Technical Specs / Material Info:

• Aluminum construction
• Four mounting bungs
• Hardware, pipes, and hoses not included

Installation Info:

• Universal fitment for K-Series turbo setups
• Custom piping may be required

Images:
