RIGID Industries Radiance+ SR-Series 30-Inch RGBW LED Light Bar - 230603

The RIGID Industries Radiance+ SR-Series 30-Inch RGBW LED Light Bar, part 230603, is an auxiliary LED light built to project focused forward light for longer-range visibility. It gives shoppers a RIGID solution with the beam, output, electrical and construction details listed below instead of borrowing specifications from a different model. Key part-specific data includes 16,320 raw lumens, 137 W power, 10.5 A draw, and 20 LEDs. The package includes Light Bar, Mounting Hardware.

Key Features & Specs:

• Part Number: 230603
• SKU: RIG230603
• Series: Radiance
• UPC: 815711014853
• Includes: Light Bar, Mounting Hardware
• Package Type: Box
• Package Dimensions: 6 x 33.6 x 6 in (H x W x D)
• Package Weight: 12 lb
• Product Weight: 6.7 lb
• Amp Draw: 10.5 A
• LED Count: 20
• Raw Lumens: 16,320
• Power: 137 W
• Output at 10 m: 1,976.4 lux
• 1-Lux Distance: 444.6 m
• Peak Beam Distance: 889.1 m
• Peak Intensity: 197,642 cd
• Field Width: 23.7°
• Field Height: 18.5°
• Warranty: 10 Years
• Same Construction As RIGID's SR-Series
• Fits All SR-Series Light Covers And Mounts
• Black Exposed Printed Circuit Board
• 8 Back Lighting Options: Red, Green, Blue, Light Blue, Purple, Amber, White Or Rotating
• 9-15 V DC
• Harness And Switch Sold Separately, Part Number 40200
• Back Lighting Independently Controlled Using Switch Logic
• Black Powder Coat Finish
• Pressure Equalizing Vent
• IP68 Compliant - Dust/Water Ingress
• High Grade Aluminum Alloy Housing And Heat Sink
• Over/Under Voltage Protection
• High Impact Polycarbonate Lens
• Mounting Brackets Included
• RFI/EMI Protection
• RoHS Compliant
• Off Road Use Only

Fitment:

• Universal fit

About the RIGID Radiance: RIGID Industries Radiance+ lighting combines functional forward illumination with independently controlled backlighting for added appearance and visibility. The family includes pod and light-bar formats with RGBW or other backlight configurations depending on the model. Voltage, backlight options, beam pattern, size and warranty coverage should be confirmed from the part-specific specifications above.
