RIGID Industries SR-L Series Spreader Flush Mounts with Red Halo Pair - 53222

The RIGID Industries SR-L Series Spreader Flush Mounts with Red Halo Pair, part 53222, is a purpose-built mounting component designed to create a clean, application-specific mounting point for compatible lighting. It gives installers a RIGID-specific hardware solution for the compatible light family or mounting location listed below. Key part-specific data includes 1,452 raw lumens, 14 W power, 1 A draw, and 2 LEDs. The package includes Light/Brackets.

Key Features & Specs:

• Part Number: 53222
• SKU: RIG53222
• Series: SR-L
• UPC: 849774004384
• Includes: Light/Brackets
• Package Type: Box
• Package Dimensions: 2.9 x 6 x 6 in (H x W x D)
• Package Weight: 1.1 lb
• Product Weight: 0.3 lb
• Amp Draw: 1 A
• LED Count: 2
• Raw Lumens: 1,452
• Power: 14 W
• Output at 10 m: 8.4 lux
• 1-Lux Distance: 29 m
• Peak Beam Distance: 57.9 m
• Peak Intensity: 838 cd
• Field Width: 120°
• Field Height: 90°
• Warranty: Limited Lifetime
• 9-36 VDC
• Pressure Equalizing Valve
• High Impact Polycarbonate lens
• Dedicated Wire to Run Backlight
• Removable Surround for Color Matching
• Wiring Harness Sold Separately #40300
• Halo Backlight Available in Blue, Red, White, and Amber
• Surface Mount and Flush Mount Available
• 120 Degree Wide Beam Pattern
• No Exposed Hardware
• Kit Includes Stainless Steel Mounting Brackets and Hardware
• High Grade Aluminum Alloy Housing and Heatsink

Fitment:

• Universal fit

About the RIGID SR-L: RIGID Industries SR-L spreader lighting is designed for wide-area illumination in marine, off-road, cargo and utility applications. The family includes surface- and flush-mount pod configurations with wide beam patterns and halo/backlight color choices on selected models. Housing color, wiring, halo color, mounting style and included hardware are part-number specific.
